Application

The BB Series globe valves are designed for handling of cryogenic liquids through bulk tanks, trucks, trailers, ISO-containers and piping configurations. Our time tested spring loaded stem packing and superior seat design provide for long life and easy maintenance. Internal components are identical with the SKB Series. The BB Series globe valves are offered with brazed-in schedule 10 and 40 stainless steel pipe stubs. Also available in short stem version.

Download data sheet REGO BB-Series

Executions of the series REGO BB

• REGO BB9402S
• REGO BB9404S
• REGO BB9406S
• REGO BB9408S
• REGO BB9412S
• REGO BB9402T
• REGO BB9404T
• REGO BB9406T
• REGO BB9408T
• REGO BB9412T
• REGO BB9416T
• REGO BB9412F
• REGO BB9416F

• REGO BBS9404AA
• REGO BBS9406AA

• REGO BBS9408AA

• REGO BBS9412AA

• REGO BBS9416AA

• REGO BBS9404BB

• REGO BBS9406BB

• REGO BBS9408BB
• REGO BBS9412BB

• REGO BBS9416BB

• REGO BBS9402S
• REGO BBS9404S
• REGO BBS9406S

• REGO BBS9408S

• REGO BBS9412S

• REGO BBS9416S

• REGO BBS9402T
• REGO BBS9404T
• REGO BBS9406T

• REGO BBS9408T

• REGO BBS9412T

• REGO BBS9416T

Application

The BK and BKA Series valves are designed exclusively for the handling of cryogenic liquids on bulk storage tanks, transports, and pipelines. These globe valves provide positive shutoff and offer a long, low-maintenance service life. The valves are available with a variety of inlet and outlet connections and stem lengths. Certain BK valves are offered with brazed-in schedule 5 and schedule 10 Stainless Steel Pipe Stubs.

Download data sheet REGO BK & BKA Series

Executions of the series

• REGO BK8404S
• REGO BK8404T
• REGO BK8404ST
• REGO BK9404S
• REGO BK9404T
• REGO BK9404AA
• REGO BK9404PT-F30
• REGO BK9404ST
• REGO BK8406S
• REGO BK8406T
• REGO BK9406S
• REGO BK9406T
• REGO BK9406AA
• REGO BK8408S
• REGO BK8408T
• REGO BK9408S
• REGO BK9408T
• REGO BK9408AA
• REGO BK9408PT-F30
• REGO BK9410S
• REGO BK9412S
• REGO BK9412T
• REGO BK9412AA
• REGO BK9412PT-F30
• REGO BK9416S
• REGO BK9416AA
• REGO BK9416T
• REGO BK941&PT-F30
• REGO BKA8408S
• REGO BKA9408S
• REGO BKA8412S

Features

• Top Entry: This union bonnet valve can be permanently installed in the line and serviced from the top. The stainless steel tube prevents stem distortion. Also available in bolted bonnet configuration.
• Construction: Bronze cast body and bonnet - Rugged construction for long life
• Designed with the unique Kold-Seal™ and high CV. standard PTFE seat design assures bubble tight seating and high cycle life.
• Oxygen cleaned per CGA G-4.1
• Sizes: ¼” through 3” (8mm through 80mm)
• Ends: Threaded (FNPT), Sil Braze Tube (SBT), Silver Braze Pipe and back brazed threaded pipe nipples
• Service: Liquefied and vaporized atmospheric gases, LNG
• Temperature Rating: -320°F to 150°F (-196°C to +65°C)
• Pressure Rating: (Cold, Non-shock) 400 and 600 psig Sizes 1½” to 3” PED approved
• Kold-Seal™ Technology assures tight seal preventing cryogen gas loss.
• Extended stem suitable for cold box, transport vehicles, pipelines, and customer service applications.
• Live (LL) loaded option improves life of asset and minimizes service costs.
• Replaceable top works equates to low maintenance costs.

Download data sheet REGO Series 222 (226LL, 226GF, 226ULL, 226BLL, 222X, 226LL, 226BLL)

Executions of the series REGO Serie 222

• REGO B-00222X-2T4
• REGO B-00222X-4T4
• REGO B-00222X-6T4
• REGO B-00222X-8T4
• REGO B-00222X-12T4
• REGO B-00222X-16T4
• REGO B-00222X-20T4
• REGO B-00222X-24T4

• REGO B-00222X-4S4
• REGO B-00222X-6S4
• REGO B-00222X-8S4
• REGO B-00222X-12S4
• REGO B-00222X-16S4
• REGO B-00222X-24S4

• REGO SB00222X-12SW

• REGO B-0226LL-2T6
• REGO B-0226LL-3T6
• REGO B-0226LL-4T6
• REGO B-0226LL-6T6
• REGO B-0226LL-8T6

• REGO B-0226LL-4S6
• REGO B-0226LL-6S6
• REGO B-0226LL-8S6

• REGO B-226ULL-12T6
• REGO B-226ULL-16T6

• REGO B-226ULL-12S6
• REGO B-226ULL-16S6

• REGO VB-226XGF-4T6
• REGO VB-226XGF-6T6
• REGO VB-226XGF-8T6
• REGO VB-226XGF-12T6

• REGO B-226BLL-12T6
• REGO B-226BLL-16T6

• REGO B-222X-2T4
• REGO B-222X-4T4
• REGO B-222X-4T4A
• REGO B-222X-6T4
• REGO B-222X-6T4A
• REGO B-222X-8T4
• REGO B-222X-8T4A
• REGO B-222X-12T4
• REGO B-222X-12T4A
• REGO B-222X-16T4
• REGO B-222X-16T4A
• REGO B-222X-20T4
• REGO B-222X-24T4A

Features

• Top Entry: This union bonnet valve can be permanently installed in the line and serviced from the top
• Construction: Rugged construction for long life, bronze cast body and bonnet
• Designed with the unique Kold-Seal™ and high CV. Standard PCTFE seat design assures bubble tight seating and high cycle life
• Sizes: ¼” through 2” (8mm through 50mm)
• Ends: Threaded (FNPT), Sil Braze Tube (SBT), or with stainless steel pipe nipples brazed in.
• Service: Liquefied and vaporized atmospheric gases, LNG
• Pressure Rating: (Cold, Non-shock)
  - 202 Series Rated for 400 psig
  - 206 Series Rated for 600 psig
  - Sizes 1.5” to 2.0” PED approved per EN10204, 3.1
• Kold-Seal™ Technology assures tight seal preventing cryogen gas loss. Non-extended stem for selective cold gas service.
• Cleaned for Oxygen Service per CGA G-4.1.

Download data sheet REGO Series 202X

Executions of the series REGO 202X

• REGO B-00202X-12T4
• REGO B-00202X-16T4

• REGO B-00202X-4S4
• REGO B-00202X-8S4
• REGO B-00202X-12S4
• REGO B-00202X-16S4

• REGO VB-0206GF-2T6
• REGO VB-0206GF-4T6
• REGO VB-0206GF-6T6
• REGO VB-0206GF-8T6
• REGO VB-0206GF-12T6
• REGO VB-0206GF-16T6

• REGO B-0206LL-2T6
• REGO B-0206LL-3T6
• REGO B-0206LL-4T6
• REGO B-0206LL-6T6
• REGO B-0206LL-8T6

• REGO B-0206LL-4S6
• REGO B-0206LL-6S6
• REGO B-0206LL-8S6

• REGO B-206ULL-12S6
• REGO B-206ULL-16S6

• REGO B-206BLL-12S6

Application

The SKB Series globe valves are designed for the handling of cryogenic liquids through trailer, bulk tanks and piping configurations. Our time tested spring loaded stem packing and superior seat design provide for long life and easy maintenance. Internal components are the same for BBS and BB Series. Also available in short stem version.

Download data sheet REGO Serie SKB

Executions of the series REGO SKB

• REGO SKB009402BW
• REGO SKB009402SW
• REGO SKB009404BW
• REGO SKB009404SW
• REGO SKB009406BW
• REGO SKB009406SW
• REGO SKB009408BW
• REGO SKB009408SW
• REGO SKB009412BW
• REGO SKB009412SW
• REGO SKB009416BW
• REGO SKB009416SW

• REGO SKB9402BWS
• REGO SKB9404BWS
• REGO SKB9406BWS
• REGO SKB9408BWS
• REGO SKB9412BWS
• REGO SKB9416BWS

• REGO SKB9402SWS
• REGO SKB9404SWS
• REGO SKB9406SWS
• REGO SKB9408SWS
• REGO SKB9412SWS
• REGO SKB9416SWS

Application

The SK Advantage Series of Stainless Steel Globe Valves are designed for handling cryogenic liquids through trailer, bulk vessels and piping configurations. Ideal service medium includes oxygen, nitrogen, krypton, carbon dioxide, dinitrogen monoxide, carbon dioxide, methane, ethane, ethylene, argon and LNG . Our Kold-Seal stem seal technology assures a tight seal preventing cryogen gas loss. The conical seat design allows exceptional flow, positive shutoff and less chance of debris accumulation in the flow path, all resulting in an overall longer service life. Maintenance on the packing and seat is quick and easy.

Download data sheet REGO Series SK

Valves with long, medium & short stem, and also available as corner valves

Executions of the series REGO SK

• REGO SKL9402SW
• REGO SKL9404SW
• REGO SKL9406SW
• REGO SKL9408SW
• REGO SKL9412SW
• REGO SKL9416SW
• REGO SKL9402BW
• REGO SKL9404BW
• REGO SKL9406BW
• REGO SKL9408BW
• REGO SKL9412BW
• REGO SKL9416BW

• REGO SKM9402SW
• REGO SKM9404SW
• REGO SKM9406SW
• REGO SKM9408SW
• REGO SKM9412SW
• REGO SKM9416SW

• REGO SKM9402BW
• REGO SKM9404BW
• REGO SKM9406BW
• REGO SKM9408BW
• REGO SKM9412BW
• REGO SKM9416BW

• REGO SKS9402SW
• REGO SKS9404SW
• REGO SKS9406SW
• REGO SKS9408SW
• REGO SKS9412SW

• REGO SKS9402BW
• REGO SKS9404BW
• REGO SKS9406BW
• REGO SKS9408BW
• REGO SKS9412BW

• REGO SKA9408LSW
• REGO SKA9412LSW

Features

• Top Entry: This valve can be permanently installed in the line and serviced from the top
• Soft Seated: PCTFE Seat provides a bubble tight seal and is replaceable
• Construction: Body and Bonnet ASTM A351 J92600 Stainless steel
• Sizes: ½” - 4” (15mm - 100mm)
• Ends: RF Flange, Butt weld, Socket weld, Threaded (FNPT)
• Service: Liquefied and vaporized atmospheric gases, LNG
• 100% Factory Tested
• Clean for use in oxygen per CGA G-4.1
• Temperature Rating: -320°F - 150°F (-196°C +65°C)
• Pressure Rating: (Cold, Non-shock)
  - Class 150 valve - 275 psig (19 barg)
  - Class 300 valve - 720 psig (50 barg)
  - ½” - 4” Class 150 - PED Approved
  - ½” - 4” Class 300 - PED Approved

Download data sheet REGO 210 Series

Executions of the series REGO 210

• REGO GS-00210W-8F
• REGO GS-00210W-16F
• REGO GS-00210W-24F
• REGO GS-00210W-32F

• REGO GS-00210W-4S3
• REGO GS-00210W-4T3
• REGO GS-00210W-6S3
• REGO GS-00210W-6T3
• REGO GS-00210W-8S3
• REGO GS-00210W-8T3
• REGO GS-00210W-12S3

• REGO GS-00210W-16W3A
• REGO GS-00210W-16W3J
• REGO GS-00210W-24W3A
• REGO GS-00210W-24W3J
• REGO GS-00210W-32W3A
• REGO GS-00210W-32W3J

• REGO LOX-00210W-24W3A
• REGO LOX-00210W-32W3A

Application

The RegO Goddard 231 Series Stainless Steel globe valves are designed for handling of cryogenic liquids through bulk tanks, trailers, ASU plants and piping configurations. Compatible with oxygen, nitrogen, CO2, hydrogen, helium and argon.

Download data sheet REGO Series 231

Executions of the series REGO 231

• REGO S-000231-2S4
• REGO S-000231-4S4
• REGO S-000231-6S4
• REGO S-000231-8S4
• REGO S-000231-12S4

• REGO S-000231-4WA
• REGO S-000231-8WA
• REGO S-000231-12WA

Application

The RegO Goddard 232 Series Stainless Steel globe valves are designed for handling of cryogenic liquids through bulk tanks, trailers, ASU plants and piping configurations. Compatible with oxygen, nitrogen, CO2, helium and argon.

Download data sheet REGO Series 232

Executions of the series REGO 232

• REGO S-000232-4S4
• REGO S-000232-8S4

• REGO S-232HCB-4WA
• REGO S-232HCB-8WA
• REGO S-232HCB-12WA

• REGO S-232HCB-4S4
• REGO S-232HCB-8S4
• REGO S-232HCB-12S4

Application

The 2500 & 2550 series valves are designed for use in hospital and industrial piping systems where gases are supplied from a central source to branch outlets throughout the system.

Download data sheet REGO Series 2500 & 2550

Executions of the series REGO 2500 & 2550

• REGO 2505AC
• REGO 2507AC
• REGO 25011AC
• REGO 25013AC

• REGO 2554AC
• REGO 2554AAC
